Raychem C910-485 - 1.3 Product Specification: Sensor Inputs & Alarm Outputs

nVent.com | 6
Monitoring
Temperature
Low alarm range 0°F to 180°F (–18°C to 82°C) or OFF
High alarm range
0°F to 200°F (–18°C to 93°C) or OFF
Ground fault
Alarm range 20 mA to 100 mA
Trip range
20 mA to 100 mA
Current
Low alarm range 0.3 A to 30 A or OFF
Autocycle
Diagnostic test interval adjustable from 1 to 240 minutes
or 1 to 240 hours
Temperature Sensor Inputs
Quantity
Two inputs standard
Types
100 Ω platinum RTD, 3-wire, α= 0.00385 ohms/ohm/°C
Can be extended with a 3
-
conductor shielded cable of 20
Ω
maximum per conductor
Alarm Outputs
AC relay
Isolated solid-state triac, SPST, 0.75 A maximum, 100 V
to 277 V nominal
Dry contact relay
Pilot duty only, 48 V/dc, 500 mA maximum, 10 VA
maximum resistive switching
Note: Outputs are configurable as “open on alarm” or “close on alarm”
