Raycus RFL-C3000S-CE User Manual

16
CAUTIONS:
 Inspect the output lens before installing the output head to the
processing head. Clean the output lens if necessary.
 It is strictly prohibited to disassemble the output head by personnel not
approved by Raycus, or the warranty is void.
3.3 Cooling Requirements
Table 6 Cooling Requirements
Model
RFL-C3000S-CE
Cooling Capability(W)
>7500
Minimum Flow(L/min)
22
Maximum Pressure(Bar)
7
Pipe Inner Diameter(mm)
19
Water temperature of coolingsystem(
℃
)
22
±
1
℃
a) The water temperature setting of cooling system:
22±1℃（RFL-C3000S-CE）
b) Cooling water requirements:
 It is recommended to use purified water.
 In order to prevent mould growing that may lead to pipe blockage, we recommend to
add alcohol about 10% of the total volume.
 If the product is used in an environment that ambient temperature is between -10 ℃
and 0℃, we recommend to use 30% alcohol, and replace it every two months.
 If the product is used in an environment that ambient temperature is below -10 ℃ ,
please use dual-system chillers (with heating function) and ensure uninterrupted
operation of the cooling system.
c) Requirements for output cable cooling system:
 Rate of liquid flow: 1.7-2.0 L/min;
 Pressure of liquid flow: < 0.6 MPa at the inflow;
 Type of liquid exchange junction: SMC MS-5H-6:
 Type of tube: outer diameter6; inner diameter 4;
