22
Power Cord
One End of
Power Cord
Four wires labeledL1
，
L2
，
L3and PE.
Sign
Description
L1，L2，L3-> Phase Line
PE-> Protective Earth
Note
One end of the power cord is a plug, insert it into the socket 'AC INPUT' on
the rear panel. Notice that the plug is wrong-side preventing. After inserting
it, lock it with the lever.
4.4 Interface Definitions
4.4.1 CTRL-INTERFACE Definitions
The CTRL-INTERFACE(DB-25) is for laser control, the designation and definition is
below
：
Figure 8 Diagram of CTRL-INTERFACE
Table 7 Definitions of 24 pin Ctrl Interface
PI
N
Name
LineMark
Type
Level
Drive
Current
Typical
Respon
Description
