Raycus RFL-C3000S-CE User Manual

20
4 Using the Product
Raycus CW fiber laser has stopped using the
HyperTerminal, so the HyperTerminal willnotworkwhen the
laser is powered on. Please clip the address below to download
the latest PC software and the relevant manual.
4.1 Front Panel
Figure 4 shows the front panel of RFL-C3000S-CE(take RFL-C2000 for example)：
Figure 4 Front Panel of RFL-C3000S-CE
1. POWER:Control system power indicator light, when the red light is on, it means that
the laser is powered on.
2. LASER:The laser is emitting light normally. When the green light is on, it means that
the laser is emitting light.
3. ALARM:Alarm indication, when the yellow light is on, it means that the machine
has an alarm.
4.2 Rear Panel
Figure shows the rear panel of RFL-C3000S-CE:
