Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL- RFL-C3000S-CE
17
Direction of cooling liquid: unidirectional; connect the tube with the water-pipe strictly
according to direction shown on the layer of the tube;
Type of liquid: deionized water, condensed water, pure water;
PH value of liquid: 5.5 - 9;
Filter is needed for the cooling system, and the size of the solid residual practicals
should be within 100um;
Maximum temperature of liquid: 45
℃
:
Minimum temperature of liquid: greater than the saturated dew-point 5
℃
;
Additive to the liquid: satisfies the requirements of PH value and size of solid residual
practicals as above;
Radius of the bending of the armored pipe: off-work state (i.e. transportation and
reservation): minimum radius of bending ≥ 20 cm; in-work state: minimum radius of
bending >= 30 cm;
Long-term vibration < 2 G; Impact action < 10 G.
d) Other requirements for chiller:
When starting the cooling system for the first time, check the entire water system and
the joint for water leakage. The external water pipe must be installed and connected
according to the inlet (IN) and outlet (OUT) by the laser. Otherwise, the laser may not
work properly.
If you will not use the laser for a long time, water must be emptied from the product,
and then both the inlet and outlet must be blocked with the nuts we provide. Failure to
do so may lead topermanentequipmentdamage.
CAUTION: Please set the water temperature in strictly accordance with
the requirements above. Too low temperature may lead to condensation on
the laser module and the output cable. This can cause serious damage to
the equipment.
