Image Button Description
Status LEDs Meaning of the LEDs:
LED Description
Green, flashing slowly (0.5
Hz)
All covers are closed.
Machine is ready.
Green, flashing fast (2 Hz) Minimum one cover is
open.
Blue + Green, permanent Data available. Pause-
mode active.
Green, permanent Job is running. Processing
and receiving data.
Shift-button Second operating level for further operation. Press the
Shift-button simultaneous with the buttons below to
activate the following function:
Button Description
Shift + Exhaust Air assist On/Off.
Shift + Laser head X/
Y
Laser head moves fast to
corresponding end position (X- or
Y-position).
Shift + Standby Keypad locked/unlocked.
Shift + Working table
Z, down
Working table is moving
automatic- ally downwards to the
corresponding end position.
Shift + Home Deactivates temporary home
position.
Exhaust-button
•
Press this button to switch the exhaust On/Off.
LED On: Exhaust active.
LED Off: Exhaust deactivated.
After the laser process is completed, the exhaust switches
off after some seconds ("Time to hold" in JobControl®)
automatically or when you press the button.
