Technical Datasheet
Subject to changes without notice. Errors and omissions excepted.
Modell-Identification: 8057 R500
January 2023
2/
2
Options and optional accessories
Working table
Aluminium slat cutting table
Lenses 4.0” lens
Exhaust / Vent-Set
2x external ventilators incl. accessories (hoses, hose clamps)
External variable power meter Adjust the laser power in a range of ± 20% on the fly
Control system
Laser power Adjustable from 0-100%
Hardware-interface
Connection to the PC via USB 2.0-Interface
Laser equipment and power
Laser source
Sealed CO
2
DC laser source water-cooled
Laser power: 100 W / 120 W
Sealed-off CO2 RF CeramiCore® laser source water-cooled
Laser power: 60 W
Water-cooling 16 l/min
„Ready-for-RF“ upgrade kit
Set to upgrade to a sealed-off CO2 RF CeramiCore® laser source wa-
ter-cooled
Laser power: 60 W
Dimensions and weight
Width x Depth x Height 1870 mm x 1700 mm x 1110 mm (73.62 x 66.93 x 43.7 inches)
Weight Approx. 570 kg
Ambient conditions
Mandatory ambient temperature 59° to 77° F or +15° to +25° C
Humidity 40% to max. 70%, not condensing
Dust free environment (2nd degree according to IEC 60947-1)
Safety and environment
Laser class CDRH laser safety laser class 2
Interlock Dual-channel interlock safety system
Certificates CE
Electrical
Power consumption laser 100 – 250V, ~ 1100 - 1500 W
Power consumption chiller ~ 900 W
