30.2Poweruptroubleshooting

Problemsatpowerupandtheirpossiblecausesandsolutionsaredescribedhere.

ProblemPossiblecausesPossiblesolutions

Checkrelevantfusesandbreakers.

Checkthatthepowersupplycableissoundandthatall

connectionsaretightandfreefromcorrosion.

Thesystem(orpartofit)does

notstartup.

Powersupplyproblem.

Checkthatthepowersourceisofthecorrectvoltageand

sufcientcurrent.

Troubleshooting

405
