Customizingthedatabar

Fromthehomescreen:

1.SelectCustomize.

2.SelectDatabarSet-up.

3.SelectEditDatabar.

4.Inthedatabar,selectthecellthatyouwantto

change.

TheSelectDataCategorymenuwillbedisplayed.

5.Selectthecategorythatreectsthetypeofdata

youwanttodisplayinthecell.Forexample,

Depthdata.

6.Selectthedataitem.

Thedatayouselectedisdisplayedon-screenin

theappropriatecell.

7.SelectHomeorBackwhencompleted.

Displayingstatusiconsinthedatabar

Touchscreenmultifunctiondisplaysenableyouto

displaystatusiconsinthedatabar.

Fromthehomescreen:

1.SelectCustomize.

2.SelectDatabarSet-up.

3.SelectStatusIconBarsothatOnishighlighted.

Thestatusiconsarenowdisplayedbelowthe

expandeddatabar.
