IconDescription

Rear-viewmode—imageisipped

horizontally.

Zoomsetting:2xzoom.

Zoomsetting:4xzoom.

Singleactivecontrolleronnetwork.

Multipleactivecontrollersonnetwork.

PC/laptopdetectedonnetwork.

FFC(FlatFieldCorrection)

PeriodicallythecamerawillperformaFlatField

Correction(FFC).Thiswillnetunethethermal

imagetosuitthecurrentambienttemperature.

TheFFCoperationisindicatedbyamomentary

pauseandagreenrectangledisplayedintheupper

leftofthethermalvideoimage.

24.3Controlsoverview

Thethermalcameraapplicationisavailableon

compatibleRaymarinemultifunctiondisplaysand

systems.Itincludescontrolsforthethermalcamera.

Rotarycontrol

Zoomimagein/out.

OKConrmmenuselection.

JoystickNavigatemenus.

CANCEL/BackCancelselection.

RANGEIN/OUTZoomimagein/out.

Thermalcameraapplication—xedmountcameras
