23.7PoweringoffanNMEA2000

Fusionunit

FromtheFusionlinkapplication:

1.SelecttheMenuicon.

2.SelectPoweroff.

TheFusionunitwillpoweroff.

TheFusionlinkapplicationwilldisplaytheunit

selectionpage.

23.8PoweringonanNMEA2000

Fusionunit

Withtheunitselectionpagedisplayed.

1.Selecttheunitthatyouwanttopowerup.

328
