17.11Settingwinddampingfromthe

Dataapplication

Dampingsettingsdeterminetherateatwhich

changestowindangleandwindspeeddataare

updatedonthedisplay.

FromtheDataSet-upmenu:Menu>DataSet-up.

1.SelectWindAngleDamping:

2.SelectWindSpeedDamping:

Thedefaultlevelis12.Thelevelsavailableare1

to15,1beingtheslowestupdaterateand15the

quickest.

Dataapplication

271
