AdjustingBass,Middle,andTreblecontrols

FromtheFusionlinkapplication:

1.SelecttheMenuicon.

2.SelectToneControls.

3.Adjustthecontrolstotherequiredlevels.

4.SelectBacktogobacktothemenuoptions.

5.SelectBackfromthemenuoptionstogobackto

themainscreen.

23.6Selectingthesystemtocontrol

WheremorethanoneFusionentertainmentsystem

isconnectedyoucanselectwhichsystemtheFusion

linkapplicationwillcontrol.

FromtheFusionlinkapplication:

1.SelecttheMenuicon.

2.SelectSelectFusionsystem.

Alistofavailablesystemsisdisplayed.

3.Selectthesystemyouwanttocontrol.

TheFusionlinkapplicationwillnowcontrolthe

selectedsystem.

Fusionlinkapplication

327
