PossiblecausesPossiblesolutions

TransducerdoesnothaveaspeedelementInstalltransducerwithspeedelementtoenablespeedreadings.

Incorrecttransducerselected(nospeed

displayed)

SelectatransducerthatsupportsspeedmeasurementfromtheTransducer

Set-Upmenu.

354

LightHouseMFDoperationinstructions
