e125/e127/c125/c127Physical
specications
Dimensions
•Width:354mm(13.94in.)
•Height(NOTincluding
bracket):222mm(8.74
in.)
•Height(includingbracket):
256mm(10.08in.)
•Depth(NOTincluding
cables):69mm(2.72in.)
•Depth(includingcables):
160mm(6.29in.)
Weight(bareunit)e125/c125
•3.320kg(7.32lb.)
e127/c127
•3.450kg(7.6lb.)
Weight(boxedunit)e125/c125
•4.955kg(10.9lb.)
e127/c127
•5.070kg(11.18lb.)
e165Physicalspecications
Dimensions
•Width:426mm(16.8in)
•Height(NOTincludingbracket):
281.4mm(11.1in)
•Height(includingbracket):295
mm(11.6in)
•Depth(NOTincludingcables):
68.4mm(2.7in)
•Depth(includingcables):176.6
mm(7in)
Weight(bareunit)5.6kg(12.3lb)
e7/e7DPowerspecication
Nominalsupplyvoltage12Vdc
Operatingvoltagerange
10.8Vdcto15.6Vdc
Fuse/BreakersIn-linefuse(ttedwithin
powercable)
•7A.(Standard20mm
glassfuse)
PowerconsumptionFullbrightness:
•e7—10W
•e7D—13.8W
PowerSavemode:
•e7—4.3W
•e7D—10.3W
Note:Power
consumptiongures
representaloadedsystem
andforsonarvariants
includeanactive600W
transducer.
LEN(RefertoSeatalk
ng
referencemanualforfurther
information).
1
c95/c97/e95/e97powerspecication
Nominalsupplyvoltage
12/24Vdc
Operatingvoltagerange
10.8Vdcto31.2Vdc
Fuse/BreakersIn-linefuse(ttedwithin
powercable)
•7A.(Standard20mm
glassfuse)
PowerconsumptionFullbrightness:
•c95—13.1W
•c97—16.7W
•e95—18W
•e97—22.1W
PowerSavemode:
•c95—5.9W
•c97—9.7W
•e95—11.2W
•e97—14.9W
Note:Power
consumptiongures
representaloadedsystem
andforsonarvariants
includeanactive600W
transducer.
LEN(RefertoSeatalk
ng
referencemanualforfurther
information).
1
c125/c127/e125/e127powerspecication
Nominalsupplyvoltage
12/24Vdc
Operatingvoltagerange
10.8Vdcto31.2Vdc
Technicalspecication
429
