RayNettoRJ45adaptercables
D13158-1
1
2
3
4
5
A80160
400 mm (1.3 ft)
A80151
3 m (9.84 ft)
A80159
10 m (32.8 ft)
A62360
1 m (3.28 ft)
A80276
3 m (9.84 ft)
A80272
400 mm (1.3 ft)
A80247
100 mm (3.9 in)
DescriptionTypicaluseQuantity
1
AdaptercablewithaRayNet(female)
socketononeend,andawaterproof
(female)socketontheotherend
acceptingthefollowingcableswithan
RJ45SeaTalk
hs
waterprooflocking
(male)plug:
A62245(1.5m).
A62246(15m).
AtypicaluseforthisadaptercableistoconnectaDSM300
sonarmoduletoaLightHouseMFD,usingall-waterproof
cableconnections.Thisadaptercablewillalsoacceptthe
followingRJ45SeaTalk
hs
cables,althoughtheRJ45plug
thatconnectsattheequipmentend(e.g.DSM300)willNOT
bewaterproof:
E55049(1.5m).
E55050(5m).
E55051(10m).
A62135(15m).
E55052(20m).
1
2
AdaptercablewithaRayNet(female)
socketononeend,andawaterproof
(female)RJ45socketontheother
end,alongwithalockingglandfora
watertightt.
DirectlyconnectaRaymarineradarscannerwithanRJ45
SeaTalk
hs
(male)cabletoaRayNetnetworkswitch(e.g.
HS5)orLightHouseMFD.
1
3
AdaptercablewithaRayNet(male)
plugononeend,andanRJ45
SeaTalk
hs
waterproof(male)plugon
theotherend.
ConnectalegacyG-SeriesGPM-400,C-SeriesWidescreen
orE-SeriesWidescreenMFDtoaRaymarineradarscanner
suppliedwithaRayNetpower/datacable.
1
4
AdaptercablewithaRayNet(female)
socketononeend,andanRJ45
SeaTalk
hs
waterproof(male)plugon
theotherend.
ConnectalegacyG-SeriesGPM-400,C-SeriesWidescreen
orE-SeriesWidescreenMFDtoaRayNetnetworkswitch
(e.g.theHS5).
1
5
AdaptercablewithaRayNet(female)
socketononeend,andanRJ45
SeaTalk
hs
(female)socketonthe
otherend.
ConnectaLightHouseMFDtoalegacySR6switch/
weatherreceiveroralegacy8–portSeaTalk
hs
network
switch.Anothercommonuseforthecableisinconjunction
withacrossovercoupler(E55060orR32142)toconnect
RaymarineproductswithanRJ45connection(e.g.radar
scanner,thermalcameraorDSM300)toaLightHouseMFD
orRayNetnetworkswitch(e.g.theHS5).
1
Sparesandaccessories
441
