Note:
•ItistheOEM’
sresponsibilitytoensurethatanappropriateUVresistant
inkisusedforpadprintingonthenameplaque.
•The‘Raymarine’brandingonthestandardnameplaqueispainted
usingglossblackMarabuTampaStarTPR980ink,andpadprinted
ontothenameplaque.Usingthisinktypeandprintmethodshould
besufficient.However,it’simportantthatyouperformyourown
testingtoensuresuitability.RefertotheMarabuwebsiteforinkdetails:
https://www.marabu-inks.com/
•Thisinformationisprovidedforinformationonly.Raymarinewillnotbe
heldliablefortheuseofinappropriateinkorprintingmethods.
AppendixBR
eplacingthecardreaderdoor
Thecardreaderdoorandcardslotcoverareasinglepiece.Ifthecard
readerdoororcardslotcoverbecomesdamageditcanbereplacedusing
theCardreaderdoorspare(partnumber:R70891.
TochangetheCardreaderdoorfollowthestepsbelow.
1.OpentheCardreaderdoor.
2.Unscrewthehexscrewsusinga1.3mma/fhexwrench(Allenkey).
3.Removetheplasticbar.
4.RemovetheCardreaderdoor.
5.OnthenewCardreaderdoor,insertthecardslotcoverensuringitis
correctlyseated.
6.Holdthecardreaderdoorintheopenpositionandreattachtheplastic
barandsecureusingthehexscrews,tighteningthescrewsevenly.
7.Ensureyoudonotovertightenthescrews.
8.ClosetheCardreaderdoorensuringthatitsitsflushwiththebezel
aroundthebottomofthedoor.
