3.8Partssupplied—eS7xdisplays
1
4
6
7
8
9
5
2 3
x4
D13309-1
ItemDescriptionQuantity
1
Multifunctiondisplay
1
2Panelsealgasket1
3
1.5m(4.9ft)Powercable
1
4
Suncover
1
5
Trunnionbracketandknobs1
6Documentpack1
7
Powercableprotectivecap1
8
BezelpiecesandHome/Menu
button
1
9Fixingsets4
3.9Partssupplied—eS9xandeS12x
displays
1
3
5
6
9
10
11
12
7
8
4
2
x4
D13329-1
ItemDescriptionQuantity
1
Multifunctiondisplay
1
2
Suncover
1
3Panelsealgasket1
4Trunnionbracketandknobs1
5
Documentpack1
6Powercableprotectivecap1
7
BezelpiecesandHome/Menu
button
1
8Fixingsets1
9
1.5m(4.9ft)Poweranddata
cable(Power/NMEA/Video)
4
10
SeaTalk
ng®
toDeviceNet
adaptorcable
1
11
1m(3.3ft.)SeaTalk
ng®
spur
cable
1
12
2m(6.6ft.)RayNetcable
1
26eSSeriesinstallationinstructions
