5.Positionthetransducerhangersothatthebottomfaceofthetransducerwillbeparallelwiththe
waterlineandtightenthemountingboltuntilthehangerisheldfirmlyinplace.
Thetransducerpositionwillbeadjustedfurtherduringtesting.
Note:DonotadjusttheM5screwlocatedontopofthetransducerhanger.Thisscrewlocatesthe
transducercorrectlyonthehanger,andmustnotbeadjustedunlessspecificallydirectedtodoso
(forexample,whenusingtheStepMountaccessory).
