Raymarine RV-100 RealVision 3D User Manual

Importantinformation
Obtainthecompletedocumentationforyourproduct
Thesuppliedprinteddocumentationisasubsetofthefulldocumentationavailableforyourproduct.
Important:ThelatestversionsofallEnglishandtranslatedhandbooksareavailableonthe
Raymarinewebsite.Pleasecheckthewebsitetoensureyouhavethelatestandcomplete
documentationandsafetyinformationforyourproduct.
www.raymarine.com/manuals
CertifiedInstallation
RaymarinerecommendscertifiedinstallationbyaRaymarineapprovedinstaller.Acertified
installationqualifiesforenhancedproductwarrantybenefits.ContactyourRaymarinedealerfor
furtherdetails,andrefertotheseparatewarrantydocumentpackedwithyourproduct.
Warning:Productinstallationandoperation
•Thisproductmustbeinstalledandoperatedinaccordancewiththeinstructions
provided.Failuretodosocouldresultinpersonalinjury,damagetoyourvessel
and/orpoorproductperformance.
•RaymarinerecommendscertifiedinstallationbyaRaymarineapprovedinstaller.
Acertifiedinstallationqualifiesforenhancedproductwarrantybenefits.Contact
yourRaymarinedealerforfurtherdetails,andrefertotheseparatewarranty
documentpackedwithyourproduct.
Warning:Highvoltages
Thisproductmaycontainhighvoltages.DoNOTremoveanycoversorotherwise
attempttoaccessinternalcomponents,unlessspecificallyinstructedinthe
documentationprovided.
Warning:Switchoffpowersupply
Ensurethevessel’spowersupplyisswitchedOFFbeforestartingtoinstallthis
product.DoNOTconnectordisconnectequipmentwiththepowerswitched
on,unlessinstructedinthisdocument.
Warning:Transduceroperation
Onlytestandoperatethetransducerinthewater.DoNOToperateoutofwater
asoverheatingmayoccur.
Caution:Serviceandmaintenance
Thisproductcontainsnouserserviceablecomponents.Pleasereferall
maintenanceandrepairtoauthorizedRaymarinedealers.Unauthorizedrepair
mayaffectyourwarranty.
Wateringress
Wateringressdisclaimer
AlthoughthewaterproofratingcapacityofthisproductmeetsthestatedIPXstandard(refertothe
product’s
Technical Specification ),waterintrusionandsubsequentequipmentfailuremayoccurif
theproductissubjectedtocommercialhigh-pressurewashing.Raymarinewillnotwarrantproducts
subjectedtohigh-pressurewashing.
Disclaimer
Raymarinedoesnotwarrantthatthisproductiserror-freeorthatitiscompatiblewithproducts
manufacturedbyanypersonorentityotherthanRaymarine.
