Raymarine RV-100 RealVision 3D - Attaching the Connector Locking Collar; Slide Locking Collar onto Connector

Attachingtheconnectorlockingcollar
Thetransducercable’sconnectorissuppliedwithaseparatelockingcollarassembly,usedtosecure
thecablefirmlytoyourmultifunctiondisplay.
Thisproceduredescribeshowtoattachthelockingcollartotheconnector.Thelockingcollarparts
aresuppliedinaseparatebag,intheboxwithyourtransducer.
Important:Ensurethatyouroutethecableallthewaytoyourmultifunctiondisplaybefore
attachingthelockingcollar.
1.Slidethelockingcollarovertheendoftheconnector,thenpushittowardsthecable-endof
theconnector.
Important:Ensurethatthelugsonthelockingcollar(labelled‘A’intheillustration),areclosestto
theplug-endoftheconnector.
2.Slidethesplit-ringovertheendoftheconnector,thenpushittowardsthecable-endofthe
connector.
Important:Ensurethatthetabsonthesplit-ring(labelled‘B’intheillustration),areclosesttothe
cable-endoftheconnector.
