Raymarine SmartPilot SPX-10 - Installation checklist; Inboard autopilot system

2.1Installationchecklist
Installationincludesthefollowingactivities:
InstallationTask
1Planyoursystem
2
Obtainallrequiredequipmentandtools
3
Siteallequipment
4Routeallcables.
5
Drillcableandmountingholes.
6Makeallconnectionsintoequipment.
7
Secureallequipmentinplace.
8Powerontestthesystem.
Schematicdiagram
Aschematicdiagramisanessentialpartofplanninganyinstallation.
Itisalsousefulforanyfutureadditionsormaintenanceofthe
system.Thediagramshouldinclude:
•Locationofallcomponents.
•Connectors,cabletypes,routesandlengths.
2.2Inboardautopilotsystem
Atypicalinboardautopilotwillconsistoftheitemsshown:
SMARTPILOT
3
4 5
1
2
D10 43 2-2
1.Autopilotcontrolhead—Thisprovidesthedisplayand
controlsrequiredtousetheautopilot.Multiplecontrollerscanbe
addedifrequired,forexampleacontrollerateachhelmposition.
12
SPXSmartPilotinstallationinstructions
