Chapter 1: Installation and system overviews 3
Example SeaTalk system
SeaTalk allows connection of compatible products though a dedicated data bus, to
allow information sharing around the ship.
Depth
transducer
GPS
ST60+ depth
instrument
SeaTalk
cable
SeaTalk
cable
SeaTalk or NMEA
SeaTalk
cable
SeaTalk
cable
SeaTalk cable, carries:
- 12V power from Course computer
- Data to and from Course computer
SeaTalk
cable
ST60+ speed
instrument
Course computer
ST6002
SmartController
Speed
transducer
SeaTalk
3-way block
D10628-1
ST6002
SmartController
12 V dc
