65
Pilot Controller (ST6002)
Nominal supply voltage: 12 V dc via SeaTalk
Operating voltage range: 10 V to 16 V dc
Current consumption (Standby mode) 60 mA (less than 200 mA with full lighting)
Environmental conditions:
• operating temperature
• storage temperature
• relative humidity limit
• water protection
-10°C to 50°C (14°F to 122°F)
-20°C to 65°C (-4°F to 149°F)
95% Relative Humidity (non condensing)
water ingress protection to IPX6.
Overall dimensions:
•width
• height
• depth
110 mm (4.33 in)
115 mm (4.53 in)
41 mm (1.62 in)
Keypad: 8 button illuminated keypad
Liquid Crystal Display (LCD): shows heading, locked course and navigational data, and up
to 15 data pages
LCD illumination: 3 brightness levels + off
Input connections: SeaTalk (x2) and NMEA 0183
Output connections:
SeaTalk (x2)
CE approvals: Europe 2004/108/EC (EMC).
Australia and New Zealand: C-Tick, Compliance Level 2.
