Raypak 131 - Specifications

TM018 Raypak 131 Type A Pool & Spa Heaters REV: A
D.O.I: 8/04/2009
This document is stored and maintained electronically by Service. All printed copies not bearing this statement in RED are deemed “uncontrolled”
4
Specifications
P0131NCO
P0131PCO
Injector size (mm)
1.36
0.77
Burner Pressure (kPa)
0.85
2.64
Minimum Gas Pressure (kPa)
1.13
2.75
Maximum Gas Pressure (kPa)
3.5
Input (MJ)
120
Number of burners
15
Gas inlet connection
RP¾/20
Header connection
40mm
Gas valve
Pre 2007
White Rogers 36E06-301
Post 2007
White Rogers 36G22-216
Ignition module
RAM-H4M7-01
Control board
Millennium grey or black board (24VAC 50Hz)
45ºC inlet high limit
Campini TY60, opens 45ºC closes 35ºC (+/- 3ºC)
55ºC outlet high limit
36TXVG11, opens 55 ºC closes 45 (+/- 3ºC)
Transformer
Primary winding 240 Volts AC 50Hz 62.2 ohms
Secondary winding 24 Volts AC 50Hz 1.3 ohms
Pressure switch¹
Barksdale MSPS-EE05-Q71 or Tecmark MSPS-EE05
Adjustable: 3.5 – 34.5kPa, max pressure 55kPa
Flow switch¹
Adjustable: max pressure 1000kPa
40ºC temperature probe
Refer to table on page 40
Control circuit fuse
3A
Relay 1²
Omron LY2N, DPDT, 24VAC, coil resist 186 ohms
Relay 2²
Omron LY2N, DPDT, 24VAC, coil resist 186 ohms
Reset illuminated push button
24VAC LED, 1 X N/O momentary contact
Flow Rate (l/s)
Minimum
1.3
Maximum
6.9
Power Supply
240VAC 50Hertz
¹ The installation will have either a pressure switch or a flow switch depending upon the application (refer to
'Water Pressure Switch‟ on page 17 for more information).
² Models manufactured from the 14/4/09 feature an integrated PCB with power outage auto reset
incorporating the relays.
Auxiliary Component Specifications
Component
Electrical Interface Board (E.I.B)
Millennium 56659201 240VAC (30A max @ 240V)
Note: Auxiliary components are optional and may not be installed.
