Raypak 131 - Replacement Parts List

TM018 Raypak 131 Type A Pool & Spa Heaters REV: A
D.O.I: 8/04/2009
This document is stored and maintained electronically by Service. All printed copies not bearing this statement in RED are deemed “uncontrolled”
58
Replacement Parts List
Item
Description
Part Nº
Item
Description
Part Nº
1
Base Panel
56320474
28
Burner Assembly – Polidoro NG
56320497
2
Electrical Enclosure
56144829
Burner Assembly – Polidoro Propane
56320496
3
Front Access Panel
56320412
29
Gas Connector – Dormont
56320476
4
Panel Electrical Enclosure Cover
56144830
30
Panel – Gas Valve Cover
56144828
5
Fuse Holder
56659145
31
Panel – Gas Valve Enclosure
56144827
Fuse 3A
56659146
32
Gas Valve – Natural Gas
56320218
6
Relay 24V (pre 14/4/09)
56659014
33
Pipe Extension
56509196
PCB - Auto Reset (post 14/4/09)
56PE5006
34
Flue Collector
56320473
7
Relay Base
56659011
35
Panel – Diverter Draft Intake
56320406
8
Transformer 240/24VAC
56650931N
36
Flue Diverter Assembly
56320472
9
Ignition Module
56601004
37
Panel – Jacket Upper Front & Rear
56320402
10
Switch – Reset
56659098
38
Panel – Jacket Top
56320405
11
Panel – Display
56320410
39
Panel – Heat Shield Header Cover
56144824
12
Controller – Grey Board
56659197
40
Panel – Header Cover Wrapper
56144814
Controller – Black Board
56PE5001
41
Panel – Header Cover Lid
56144813
13
Panel – PCB Control Cover
56144826
42
Panel – Access In/Out Header
56144832
14
Cover – Igniter
56144825
43
Panel – Access Lower Rear
56320420
15
Igniter – HSI Norton
56659144
44
Panel – Access Upper Rear
56320432
16
Panel – Jacket Side LH
56320400
45
Header – In/Out
56320495
17
Panel – Jacket Side RH
56320408
46
Cap – Bypass
56320486
18
Panel – Support Front Refractory
56320433
47
O-ring Bypass Cap
56320481
19
Panel – Support Rear Refractory
56320403
48
Spring – Bypass
56320482
20
Channel – Refractory Support (Left & Right)
56320416
49
Valve – Bypass Disc
56800369
21
Fire Tile Kit
56700466
50
O-ring – Header Connection
56320479
22
Thermostat – Hi Limit 55° Auto Reset
56601547
51
Union Nut – Header Connection
56320477
23
Channel – Refractory Support (Front & Rear)
56320415
52
Union Tail – Header Connection
56320478
24
Fibreglass Tape
56700702
53
Locator - Sensor Probe and Hi Limit
56659206
25
Panel – Hi Limit Cover
56144839
54
Water Temperature Sensor
56659202
26
Bracket Support – Gas Tray
56320428
55
Thermostat – Hi Limit 45° Auto Reset
56600188
27
Heat Exchanger
56320499
56
Pressure Switch
56651284
57
Cordset
56659143
