Raypak CROSSWIND Series - Technical Parameters; Inverter Model Specifications

22
9. TECHNICAL PARAMETERS
Inverter Models Only
Parameter
Crosswind Inverter Models
30-I 40-I 50-I 65-I
Max intended pool volume gallons (liters)
2113
(8000)
2906
(11000)
3698
(14000)
4755
(18000)
Operating air temperature
32~109°F (0~43°C)
Performance Condition: Air 80°F (27°C), Water 80°F (27°C), Humidity 80%
Heating capacity (BTUH)
30,000 40,000 50,000 65,000
Heating capacity (BTUH) in silent mode
24,000 32,000 40,000 52,000
COP
10.0~5.8 10.3~6.0 10.6~5.98 11.2~5.61
Performance Condition: Air 80°F (27°C), Water 80°F (27°C), Humidity 63%
Heating capacity (BTUH)
28,500 38,255 47,500 56,000
Heating capacity (BTUH) in silent mode
22,800 31,000 37,200 44,800
COP
9.0~5.4 9.1~5.86 9.7~5.5 9.9~5.35
Performance Condition: Air 50°F (10°C), Water 80°F (27°C), Humidity 63%
Heating capacity (BTUH)
18,300 24,500 28,900 37,000
Heating capacity (BTUH) in silent mode
14,600 15,000 20,295 26,970
COP
4.4~4.0 4.5~4.0 5.1~4.15 5.2~4.3
Rated input power (kW)
0.2~1.5 0.23~1.95 0.28~2.45 0.34~3.4
Rated input current (A)
0.86~6.52 1~8.48 1.22~10.65 1.48~14.78
Power supply
208-230VAC/ 1 Ph/60Hz
Refrigerant (R410A) in oz. 28.2 31.7 38.8 45.9
Advised water ux GPM (L/min)
13.2~17.7
(50~67)
17.7~26.4
(67~100)
21.9~30.6
(83~116)
28.5~37.5
(108~142)
Sound pressure 39" (3 m) dBA
33.4~45.2 33.6~45.5 34.9~45.0 38.2~49.3
Heat exchanger
Titanium in PVC
Casing
ABS casing
Air discharge
Horizontal
Water pipe in-out Spec inches
1-1/2
Net Dimension LxWxH inches (mm)
34x14.1x25.5
(864x359x648)
37.8x13.7x25.9
(961x348x648)
37.8x13.7x25.9
(961x348x658)
37.8x15.4x25.9
(961x390x658)
Net Weight lbs (kg)
222.7
(101)
277.8
(126)
330.7
(150)
379.2
(172)
* The values indicated are valid under ideal conditions: Pool is well covered, ltration system running at least 15 hours a day.
* The nal specs will be in accordance with the specs of the product
Table J. Technical Parameters - Inverter Models Only
