M 20X Digital Mixer Reference Guide
RECORDER
The REC tab allows high-quality, stereo or multitrack recordings according to the SETUP configuration. The currently
available format is 24-bit, 48 kHz (the internal sample rate of the M 20 Digital Mixer).
Stereo Player files can be reproduced by
channels 19-20 according to channel routing.
Multitrack Player files can be reproduced on the
corresponding channels when SD CARD source is
selected for each channel.
When in STEREO mode, all stereo recordings are
stored in the /REC folder within the USB Mass
Storage devices (up to four different drives), with
source points fully configurable through the IO
routing page.
When in MULTITRACK mode, all multichannel
recordings are stored in the /REC folder within the
SD Card, with channels tap points configurable
through the IO routing page. You can record all 20
input channels or you can configure your recorder
with a reduced number of channels to optimize the
SD Card files size.
A default name is generated if no specific name is entered, of
the form m20_rec_XXXX_0.wav, where XXXX is a numeric
counter to ensure a unique filename.
To modify the filename touch this area and type the new file
name; press Enter to confirm
Record bar
Rec/Stop
Elapsed Time
Remaining Time (size
available on your device)
To Next Page
