RCF M 20 Series User Manual

RCF spa
M 20X Digital Mixer Reference Guide
59
OUTPUT PROCESSING
MIX 1-8 (option to link in stereo pairs)
8-band Parametric EQ
Compressor/Limiter
Delay (up to 250 ms)
MAIN LR output (with Stereo/Mono switch)
30-band Graphic EQ
8-band Parametric EQ
Compressor/Limiter
Delay (up to 250 ms)
PAFL
Real-Time Analyzer
Delay (up to 250 ms)
INTERNAL FX (4x Z-CORE FX Engine)
FX1 bus
Stereo Reverb (Hall, Plate, Room, Ambience)
FX2 bus
Stereo Reverb (Hall, Plate, Room, Ambience)
FX3 bus
Stereo Delay (Stereo, Modern, Vintage, Dual, ER)
FX4 bus
Stereo Delay / Modulation (Chorus, Flanger, Tremolo)
ON-BOARD MULTITRACK
SD Card Play/Rec
Recording: 20 channel WAV, 48kHz 24-bit, patchable
Playback: 20 channel WAV, 48kHz 24-bit, patchable
USB Audio Interface
Upstream: 24 channel WAV, 48kHz 24-bit, patchable
Downstream: 24 channel WAV, 48kHz 24-bit, patchable
USB DRIVE PLAY/REC
2-channel Play/Rec
Recording: WAV 48kHz, 24-bit
Playback: WAV (16/24-bit), MP3, AIFF; allowed sample rates from 44.1 to 96 kHz
CONTROL INTERFACES
LAN
1000-BaseTX for remote control
Dual 1000-BaseTX for Dante audio streaming (M 20XD / M 20RD)
USB host
2 ports
MIDI interface, WiFi dongle (must be enabled), USB mass storage
POWER
Input Voltage Range
100-240 VAC, 50/60 Hz
Power Requirements
70 W (M 20X/M 20XD) / 70 W (M 20R/M 20RD)
PHYSICAL
Ambient Operating Temperature
35°C
Weight
7.9 kg (M 20X / M 20XD) / 5.9 kg (M 20R / M 20RD)
Dimensions [D x L x H]
428 x 388 x 131 mm (M 20X / M 20XD) / 285 x 440 x 132.5 mm (M 20R / M 20RD)
