RCH Onda - Fiscal Code and Alphanumerical String Printing; Fiscal Code Printout; Alphanumerical String Printout

51
7.14 FISCAL CODE AND ALPHANUMERICAL STRING
To print an alphanumerical line or the customer’s fiscal code into the
receipt, follow the following instructions in REG mode (1 + KEY);
7.14.1 FISCAL CODE PRINTOUT
Before starting the recording of the articles, it is necessary to enter the
fiscal code by pressing the key FISCAL CODE. The display shows
Enter the fiscal code using the numerical keys (see chapter 4). Once
entered the characters, press the key CASH. The program will verify the
correctness of the data entered. On the contrary it will ask for re-entering
the code. If the code F.C. or VAT code has been properly entered, it will
be printed on the receipt (figure 3).
NOTE: the fiscal code may be entered
with a receipt being worked. However,
the printout will be performed at the
end of the recordings.
Fig. 3
RCH S.P.A.
VIA CENDON, 39
SILEA (TV)
MODELLO ONDA
F.C. 00193390267
DEPART. 01 F 50.00
-----------------
SUB-TOTAL F 50.00
TOTAL 50.00
CASH 50.00
CLK#1 PC#1
N.0013 16/01/05 12:49
GM GD 72000001
FISCAL CODE
PRINTOUT
FISCAL CODE ?
<
_
>01
52
7.14.2 ALPHANUMERICAL STRING PRINTOUT
Within a receipt, it is possible to print one or more alphanumerical lines,
during the recording of the articles. For the insertion press the key FN
and ALPHA PRINTOUT.
The display would show
Enter the characters (max 23) using the numerical keys (see chapter 4).
Once the operation to enter the characters is completed, press the key
CASH. The line is printed on the fiscal receipt (figure 4).
Figure 4
RCH S.P.A.
VIA CENDON, 39
SILEA (TV)
MODELLO ONDA
#12345ABCDEFG
REPARTO 01 F 50.00
#56789LMNOPQR
DEPART. 02 F 30.00
-----------------
SUB-TOTAL F 80.00
TOTAL 80.00
CASH 80.00
CLK#1 PC#2
N.0014 16/01/05 12:50
GM GD 72000001
ALPHANUMERICAL
LINE
TEXT?
<
_
>01
