Schedule Operation
Setting the Schedule Mode
The Schedule button sets the schedule operation to RUN or HOLD mode. It also allows you to select
three different setback modes, HOME, AWAY and VACATION.
Pressing the Schedule button in the main Thermostat Control Screen will take you to the SCHEDULE
MODE menu screen as shown below.
Select the mode desired with the Up/Down buttons and press the Done button to select and exit.
Schedule Mode Screen
Schedule Modes:
RUN Mode. In the run mode, the thermostat schedule is running and setpoints will change according the
times and temperatures in the internal schedule.
HOLD Mode. This holds the current temperature setpoint settings. The schedule operation is disabled.
HOME Mode. This is an energy saving setback mode. When selected, the HOME mode setback heating
and cooling setpoints are used. It also inhibits schedule operation. HOME mode setpoints are set in the
Main Menu “Economy Settings” submenu.
AWAY Mode. This is an energy saving setback mode. When selected, the AWAY mode heating and
cooling setback setpoints are used. It also inhibits schedule operation. AWAY mode setpoints are set in
the Main Menu “Economy Settings” submenu.
VACATION Mode. This is an energy saving setback mode. When selected, the VACATION mode
heating and cooling setback setpoints are used. It also inhibits schedule operation. VACATION mode
setpoints are set in the Main Menu “Economy Settings” submenu.
Select Schedule mode
with Up or Down
buttons.
.
SCHEDULE MODE
RUN
HOLD
HOME
AWAY
VACATION
DONE
Down
Up
Press DONE button to select mode and exit
back to main thermostat Control screen.
HOLD
Pressing the Schedule button will also step
through the Schedule modes.
