12
Main menu - Schedules
Thermostat Schedule Selection
The thermostat has a day and time heating and cooling setpoint temperature adjustment scheduler. It
provides a 4x7 schedule, which has four times a day for each day of the week, for which separate heating
and cooling setpoints can be programmed.
When the schedule mode is set to “Run” mode, the programmed heating and cooling setpoint will be
changed daily according to the schedule.
When set to “Hold” mode, the schedule operation is stopped and the thermostat holds the current
setpoints until changed manually or by network commands.
The thermostat come preloaded with the “Comfort” schedule. The user can customize this schedule as
desired for each day, time and heating/cooling setpoint. There are also two preset preprogrammed
schedules that can be reloaded at any time.
From the Main Menu screen, select Schedules to go to the Select Schedule screen. Using the Up/Down
buttons, select to edit the existing Heat and Cool schedule, or to select one of the two preset schedules.
Press Select button go the schedule edit or load screen. Press Done button to return to the Main Menu.
Schedules Screen
Menu Options
Heat and Cool: You can change the individual day/hour and setpoints for the Heating and
Cooling schedule by selecting this menu item.
Preset: Comfort: This is a preset schedule with mild setbacks. Select this menu item to load
the Comfort schedule into the thermostat. Confirmation screen will be displayed for Yes/No entry.
Preset: EnergyMiser: This is a preset schedule with deeper setbacks. Select this menu item to
load the EnergyMiser schedule into the thermostat. Confirmation screen will be displayed for
Yes/No entry.
Select menu item with
Up or Down buttons.
Press DONE button to exit back to main
thermostat screen.
Pressing SELECT button will also step
through the schedule options.
Heat and Cool
Preset: Comfort
Preset: EnergyMiser
To Next Page
