11
Main Menu
The Menu button on the main Thermostat Control Screen selects the MAIN MENU screen. The Main
Menu is a list of the primary thermostat setting screens. Selecting these items will take you to additional
submenu screens for specific settings.
Note: Some Menu items are optional and may or may not show up in the Main Menu list, depending on
whether or not they have been enabled in the Installer Settings.
Main Menu Selections
Schedules. This screen is used to view and set the programmable setback schedules of the thermostat.
User Settings. This screen is used to set the Clock, Filter Service, Maintenance Service, Screen
Timeout, F/C mode, Sensor Calibration and Backlite/Display settings.
Economy Settings. Sets the energy savings Home, Away and Vacation setback heating and cooling
setpoints.
Thermostat Info Screen: This screen shows the firmware versions of the Thermostat’ s Wall Display
Unit and HVAC Control Unit, HVAC system type setup and RS485 network address.
Optional Menu Items.
For these to show up in the main menu list, they must be enabled in the Installer Settings.
SmartVent. Control screens for the optional SmartVent fresh air venting system.
Messaging. A messaging system to send messages to the TR65 via the RS485 network.
Select menu item with
Up or Down buttons.
.
Schedules
User Settings
Economy Settings
Thermostat Info
Press DONE button to exit back to main
thermostat screen.
Press SELECT button to go to the submenu screen.
To Next Page
