RCS TR65 User Manual

2
Model: TR65
RS485 Thermostat
This manual applies to the following product revisions or later revisions up to the next manual revision
release:
Product
Part No:
Firmware Revision
TR65 RS485 Thermostat
001-02165
Includes
TS65 Wall Display Unit
001-02102
ZCV1 HVAC Control Unit
001-01065
Document Revision History
Revision
Date
Changes
01
5/03/12
Original release
Product Specifications
Product Model: TR65
Product: Thermostat for Heating and Cooling HVAC System control.
RS485 Half Duplex 2 wire (plus gnd) communications
Wall Display Unit
Model: TS65
Size: 5.7” wide x 4.0” height x 1.2” depth
Display: Graphical LCD, 2.75” x 1.5”, 64x128 pixel
Backlight: Yes, Blue/white, Controllable, on, off, timeout
Contrast: Adjustable on screen
Buttons: 6
LEDs: 4 (3 green, 1 red)
Remote Sensors: 2, two wire, remote primary, averaging
Power: 12VDC from HVAC Control Unit
HVAC Control Unit
Model: ZCV1
Size: 8” x 6” x 1.5”
HVAC System Type Compatible: Standard (gas/electric) or Heat Pump
Multistage System Compatible:
Standard HVAC Systems: 2 stage heating, 2 stage cooling
Heat Pump Systems: 3 stage heating (2 compressor, 1 aux heat), 2 stage cooling
Heat Pump change over valve: Selectable change over with cool or with heat ( O or B)
Communications: RS485 Half Duplex 2 wire (plus gnd)
Power: 24VAC from HVAC system
