Realtek RTL8169 - PCI Configuration Space Table

RTL8169
2002/03/27 Rev.1.21
41
8.4 PCI Configuration Space Table
No. Name Type Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
00h VID R VID7 VID6 VID5 VID4 VID3 VID2 VID1 VID0
01h R VID15 VID14 VID13 VID12 VID11 VID10 VID9 VID8
02h DID R DID7 DID6 DID5 DID4 DID3 DID2 DID1 DID0
03h R DID15 DID14 DID13 DID12 DID11 DID10 DID9 DID8
04h Command R 0 PERRSP 0 MWIEN 0 BMEN MEMEN IOEN
W - PERRSP - MWIEN - BMEN MEMEN IOEN
05h R 0 0 0 0 0 0 FBTBEN SERREN
W - - - - - - - SERREN
06h Status R FBBC 0 0 NewCap 0 0 0 0
07h R DPERR SSERR RMABT RTABT STABT DST1 DST0 DPD
W DPERR SSERR RMABT RTABT STABT - - DPD
08h Revision ID R 0 0 0 0 0 0 0 0
09h PIFR R 0 0 0 0 0 0 0 0
0Ah SCR R 0 0 0 0 0 0 0 0
0Bh BCR R 0 0 0 0 0 0 1 0
0Ch CLS R/W 0 0 0 0 0 0 0 0
0Dh LTR R LT R7 LTR6 LTR5 LTR4 LTR3 LTP2 LTR1 LTR0
W LTR7 LTR6 LTR5 LTR4 LTR3 LTP2 LTR1 LTR0
0Eh HTR R 0 0 0 0 0 0 0 0
0Fh BIST R 0 0 0 0 0 0 0 0
10h IOAR R 0 0 0 0 0 0 0 IOIN
W - - - - - - - -
11h R/W IOAR15 IOAR14 IOAR13 IOAR12 IOAR11 IOAR10 IOAR9 IOAR8
12h R/W IOAR23 IOAR22 IOAR21 IOAR20 IOAR19 IOAR18 IOAR17 IOAR16
13h R/W IOAR31 IOAR30 IOAR29 IOAR28 IOAR27 IOAR26 IOAR25 IOAR24
14h MEMAR R 0 0 0 0 0 0 0 MEMIN
W - - - - - - - -
15h R/W MEM15 MEM14 MEM13 MEM12 MEM11 MEM10 MEM9 MEM8
16h R/W MEM23 MEM22 MEM21 MEM20 MEM19 MEM18 MEM17 MEM16
17h R/W MEM31 MEM30 MEM29 MEM28 MEM27 MEM26 MEM25 MEM24
18h-2
7h
RESERVED
28h-2
Bh
CISPtr Cardbus CIS Pointer
2Ch SVID R SVID7 SVID6 SVID5 SVID4 SVID3 SVID2 SVID1 SVID0
2Dh R SVID15 SVID14 SVID13 SVID12 SVID11 SVID10 SVID9 SVID8
2Eh SMID R SMID7 SMID6 SMID5 SMID4 SMID3 SMID2 SMID1 SMID0
2Fh R SMID15 SMID14 SMID13 SMID12 SMID11 SMID10 SMID9 SMID8
30h BMAR R 0 0 0 0 0 0 0 BROMEN
W - - - - - - - BROMEN
31h R BMAR15 BMAR14 BMAR13 BMAR12 BMAR11 0 0 0
W BMAR15 BMAR14 BMAR13 BMAR12 BMAR11 - - -
32h R/W BMAR23 BMAR22 BMAR21 BMAR20 BMAR19 BMAR18 BMAR17 BMAR16
33h R/W BMAR31 BMAR30 BMAR29 BMAR28 BMAR27 BMAR26 BMAR25 BMAR24
34h Cap_Ptr R 1 1 0 1 1 1 0 0
35h-3
Bh
RESERVED
3Ch ILR R/W IRL7 ILR6 ILR5 ILR4 ILR3 ILR2 ILR1 ILR0
3Dh IPR R 0 0 0 0 0 0 0 1
cont...
