RTL8169
2002/03/27 Rev.1.21
75
DEVSELB
C/BE3-0B
IRDYB
TRDYB
AD31-0
ADDRESS
DATA-1 DATA-2 DATA-3
BUS CMD BE3-0B-1 BE3-0B-2
CLK
1
23456789
FRAMEB
WAIT
DATA TRANSFER
WAIT WAIT
DATA TRANSFER DATA TRANSFER
BE3-0B-3
Memory Write below 4GB (32-bit address, 32-bit data; 32-bit slot)
