Record Power BS300 - Stand & Wheel Kit Assembly

4. Stand & Wheel Kit Assembly
4.1 Stand & Wheel Kit Assembly
CAUTION! The machine is heavy. Additional help or a
suitable lifting device or support will be required for lifting
the machine onto the stand.
The stand and wheel kit comes as a self assembly unit Fig.4.1.
Stand
1. 2 x Long mid brace supports
2. 1 x Short mid brace support
3. 2 x Long top brace supports
4. 2 x Short top brace supports
5. 4 x Legs
6. 22 x Stand fixing nuts bolts and washers (each)
Wheel Kit
7. 1 x Operating frame pedal
8. 2 x Brace support bars
9. 4 x Washers
10. 4 x Fixing pins
11. 2 x Axles
12. 1 x Release pedal
13. 2 x Back wheels
14. 2 x Front wheels
15. 1 x Operating frame
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Fig.4.1
