2
Ordering Information ...................2
General Meter Specifications .............3
Universal DC Input Panel Meter ...........4
Process Input Panel Meter ...............4
AC True RMS Voltage and Current Meter. . . . 5
Strain Gage Input Panel Meter ............5
Thermocouple and RTD Input Meter .......6
Option Cards ..........................7
Installing the Meter .....................8
Setting the Jumpers ....................8
Installing Option Cards .................10
Wiring the Meter ......................11
Reviewing the Front Buttons and Display ...14
Programming the Meter. . . . . . . . . . . . . . . . . 15
Factory Service Operations .............30
Parameter Value Chart .................32
Programming Overview ................34
Table Of COnTenTs
Ordering infOrmaTiOn
PAX
0
0
D - DC Volt/ Current Input
P - Process Input
H - AC True RMS Volt/Current Input *
S - Strain Gage/Bridge Input
T - Thermocouple and RTD Input
0 - Red, Sunlight Readable Display
1 - Green Display
0 - 85 to 250 VAC
1 - 11 to 36 VDC, 24 VAC
* PAXH is only available with 85-250 VAC power supply.
Meter Part Numbers
Option Card and Accessories Part Numbers
TYPE MODEL NO. DESCRIPTION PART NUMBER
Option
Cards
PAXCDS
Dual Setpoint Relay Output Card PAXCDS10
Quad Setpoint Relay Output Card PAXCDS20
Quad Setpoint Sinking Open Collector Output Card PAXCDS30
Quad Setpoint Sourcing Open Collector Output Card PAXCDS40
Dual Triac/Dual SSR Drive Output Card PAXCDS50
Quad Form C Relay Output Card PAXCDS60 *
PAXCDC
RS485 Serial Communications Card with Terminal Block PAXCDC10
Extended RS485 Serial Communications Card with Dual RJ11 Connector PAXCDC1C
RS232 Serial Communications Card with Terminal Block PAXCDC20
Extended RS232 Serial Communications Card with 9 Pin D Connector PAXCDC2C
DeviceNet Communications Card PAXCDC30
Modbus Communications Card PAXCDC40
Extended Modbus Communications Card with Dual RJ11 Connector PAXCDC4C
Profibus-DP Communications Card PAXCDC50
PAXCDL Analog Output Card PAXCDL10
PAXUSB PAX USB Programming Card (Not included in PAX product UL E179259 file) PAXUSB00
Accessories
CBLUSB USB Programming Cable Type A-Mini B CBLUSB01
ICM8 Ethernet Gateway ICM80000
PAXLBK Units Label Kit Accessory (Not required for PAXT) PAXLBK10
SFCRD
u
Crimson PC Configuration Software for Windows 98, ME, 2000 and XP
SFCRD200
* This card is not suitable for use in older PAX models. For proper installation, a case knock-out feature must be present on the top surface
of the PAX case. This feature began to be introduced to the standard PAX units in July of 2014 (2614).
u
Crimson® software is available for free download from http://www.redlion.net/
