VALID CONTROL MODE COMBINATIONS
ON/OFF, PID, and Manual Control can be used for O1 (heat) and O2 (cool)
outputs according to the combinations below.
O1 & O2 VALID CONTROL MODES
O1 MODE O2 MODE
MANUAL CONTROL
OUTPUT POWER
RANGE
O1 STATE O2 STATE
PID — 0% to +100% O1-TP —
ON/OFF
(ProP = 0.0)
— 100% O1-ON —
Any other setting O1-OFF —
PID PID -100% to +100% O1-TP O2-TP
PID ON/OFF
(GAN2=0.0)
0% to +100% O1-TP O2-OFF
-100% to 0% O1-TP O2-ON
ON/OFF
(ProP=0.0)
ON/OFF
(GAN2=0.0)
+100% O1-ON O2-OFF
-100% O1-OFF O2-ON
Any other setting O1-OFF O2-OFF
TP - Time Proportioning
-15-
