REFERENCE TABLES: CONFIGURATION PARAMETER MODULES
Configure Module 1 - Input Parameters (1-IN) T48
Display Parameter
Range and Units
(Factory Setting)
Description/
Comments
tYPE Input Type tc-t - Type T TC
tc-E - Type E TC
tc-J - Type J TC
tc-k - Type K TC
tc-r-TypeRTC
tc-S - Type S TC
tc-b - Type B TC
tc-N - Type N TC
LIN - Linear mV display
Thermocouple select
r385 - 385 curve RTD
r392 - 392 curve RTD
rLIN - Linear ohms display
(tc-J)
RTD select
SCAL Temperature
Scale
°F/°C
(°F)
If scale is changed,
be sure to check all
parameters.
dCPt Temperature
Resolution
0or0.0
(0)
If resolution changed,
be sure to check all
parameters.
FLtr Digital Input
Filtering And
Display
Update
0to4
(1)
Increase number for
more filtering effect.
4 = 500 msec display
update rate. Adjusted
by Auto-Tune.
Display Parameter
Range and Units
(Factory Setting)
Description/
Comments
SHFt Input Signal
Shift (correction
offset)
-999 to 9999
1 or 0.1 degree
(0)
Normally set to 0.
SPLO Setpoint Lower
Limit
-999 to 9999
0 or 0.1 degree
(0)
Set low limit
below high limit.
SPHI Setpoint Upper
Limit
-999 to 9999
1 or 0.1 degree
(9999)
Set high limit
above low limit.
SPrP Setpoint Ramp
Rate
0.0 to 999.9 degrees/minute
(0.0)
0.0 is off (no
ramping)
InPt User Input * PLOC - Program disable
ILOC - Integral action on/off
trnF - Auto/manual select
SPrP - Setpoint ramp on/off
ALrS - Reset alarm output(s)
SP2 - Select SP1/SP2
rSP - Select
Local/Remote
PrNt - Serial block print
(PLOC)
Low = lock
Low = off
Low = manual
Low = end ramp
Low = reset
Low = SP2
Low =remote
Low =block print
* Model Number Dependent
-21-
These tables are only used for programming the T48 models. Use
the tables on page 22 if you are programming a P48.
