RED STATION REDMAG 2.5" LEDS
Figure: RED STATION REDMAG 2.5" (Front)
LED COLOR/FLASHING DESCRIPTION
Power Indicator LED Off Powered off and turned off
Red Powered on and turned on
Red flashing (fast) Accessing media
RED STATION BASE
The RED STATION Base provides power to up to three (3) RED STATIONs (excluding the RED STATION REDMAG
1.8" (Mini) and RED STATION RED MINI-MAG – ESATA/USB 3.0), eliminating the need to have AC power adaptors
going to each module. This product is a great solution for those who are managing multiple RED STATIONs and want
to reduce cable clutter.
Figure: REDSTATIONBase
