Page #5 background image
Contents | 5
3 SPECIFICATIONS
Part Number BCDC1220 and BCDC220-IGN
Continuous Current Rating 20 A
Vehicle Input Fuse Rating
40 A (Not Supplied)
REDARC FK40 recommended
Output Fuse Rating
Output Power 300 W
DC Input Voltage Range
*1
9 to 32 VDC
Output Battery Type Standard Lead Acid, Calcium content, Gel or AGM type only
Charging Profile A B C
Maximum Voltage
*1
(refer to Table 2.2.1 on page 6)
14.6 V 15.0 V 15.4 V
Float Voltage
*1
13.3 V
No Load Current <100 mA
Standby Current <5 mA
Ambient Temperature −20°C to +80°C (−4°F to +176°F)
Minimum O/P Battery Volts*1 4 V
Weight 450 g (15.9 oz)
Dimensions 100×120×37 mm (3.9"× 4.75"× 1.5")
Warranty 2 years
Standards CE,C-Tick, AS/NZS CISPR11:2004
*1 Voltages Specified are ±100mV
