Redarc BCDC1220 User Manual

8 | Product Function
4.3 TURN ON/OFF THRESHOLDS
12 V BCDC1220 BCDC1220-IGN
24 V BCDC1220 &
BCDC1220-IGN
Input Open
Circuit Low
voltage
conditions
*2
Turn ON above 12.9 V 12.0 V With Ignition
Turn OFF above 12.7 V 11.9 V With Ignition
Input Loaded
Low voltage
conditions
*3
Turn OFF
instantly below
8 V
Turn OFF after
20 secs below
9 V
Input Over
voltage
shutdown
Turn ON below 32 V
Turn OFF
instantly above
32.5 V
Turn OFF after
20 secs above
32.1 V
Output Under
voltage
shutdown
Shutdown if Output Battery < 4 V
Voltages Specified are ±100 mV.
*2
Tested every 100 seconds.
*3
Constantly tested.

Redarc BCDC1220 Specifications

General

Input Voltage	9 - 32VDC
Output Voltage	12V DC
Output Current	20A
Dimensions	150mm x 120mm x 37mm
Weight	0.65 kg
Battery Types Supported	AGM, Gel, Calcium
Charger Type	DC to DC
Protection Features	Over Temperature, Short Circuit, Reverse Polarity
