6 | Manager Alpha Overview

MANAGER ALPHA OVERVIEW

KIT CONTENTS

Ref. Part Description Qty.

1 Main Unit 1

2 Battery Monitor 1

3 Display 1

4 M6 × 12 mm Pan Head Fasteners (terminal fasteners in Main Unit) 4

5 M10×20 mm Alternative Terminal Bolt 1

6 R‑Bus (RJ45) Terminating Resistor 1

7 R‑Bus (RJ45) Cable, 2 m (6'6") 2

8 Battery Sense Lead, 1 m (3'3") 1

9 a. AU Mains Cable 1.8 m (5'11")

b. NA Mains Cable 0.9 m (3')

5 6

7 (×2)

9a or 9b

4 (×4)
