PARTS OF THE BATTERY MONITOR
Control Button
Status LED
Mounting Holes (
×2)
R-Bus Network Socket
Battery Sense Lead Socket
Standard Terminal Bolt (×2)
M10 × 16 mm
PARTS OF THE DISPLAY
Up/Down
arrow
Left/Right
arrow
Power Button
Softkeys
Softkeys
SpacerBezel
The screen shown on the Display is an example only. The layout and appearance of the screen may vary depending on the Display
software version and the devices on your system.
