44 | Technical Specifications
ELECTRICAL SPECIFICATIONS
POWER INPUT
Supply Voltage
9–16 VDC ⎓
Supply Current Limit 40 A
Connector Housing Molex 428160212
Connector Contacts Molex 428150134
OUTPUT CHANNELS
Number of Channels 10
Channel Current Limit 10 A
PWM Dimming Capable Yes, All Channels
Harness Connector Molex 039012100
Connector Contacts Molex 457503111
PROTECTION
Output Overload Protection Yes
Output Short Circuit Protection Yes
Surge Protection Yes
Reverse Polarity Protection Yes
SWITCH INPUT CHANNELS
Number of Switch Inputs 8
Switch Types Supported Pushbutton or Rocker
Harness Connector Molex 430252400
Connector Contacts Molex 430300001
SENSOR INPUT CHANNELS
Number of Channels 2
Sensor Input Functions Tank Level Sensing
Sensor Input Modes Voltage (0–32 V), Resistance (0–1000 Ω)
Multi Point Calibration Yes, up to 10 points
Sensor Supply Voltage System Voltage + 0 V / –2 V
Sensor Supply Current 80 mA maximum
Tank Sensors Supported 0–5 V, 0.5–4.5 V, 240–33 Ω, 0–190 Ω
Harness Connector Molex 430252400
Connector Contacts Molex 430300001
THERMAL SPECIFICATIONS
Operating Temperature −20°C to +70°C / −4°F to +158°F
Overtemperature Shutdown Progressive Load Shedding
