Reer EOS4 User Manual

EOS4 SAFETY LIGHT CURTAIN
8540733 • 10th February 2009 • Rev.1 25
English
30 mm Resolution Models
153 303 453 603 753 903 1053 1203 1353 1503
Number of beams
8 15 23 30 38 45 53 60 68 75
Response time
(EOS models)
ms
4 5,5 7,5 8,5 10,5 12 14 15,5 17 18,5
Response time
(Master + 1 slave)
ms
t
tot
= [0,11 * (Nr
slave1
+ Nr
master
) + 0,9376] * 2
Response time
(Master + 2 slaves)
ms
t
tot
= [0,11 * (Nr
slave1
+ Nr
slave2
+ Nr
master
) + 1,0508] * 2
Protected height
mm 160 310 460 610 760 910 1060 1210 1360 1510
Curtain tot. height mm
236.5 386.5 536.5 686.5 836.5 986.5 1136.5 1286.5 1436.5 1586.5
40 mm Resolution Models
154 304 454 604 754 904 1054 1204 1354 1504
Number of beams
5 10 15 20 25 30 35 40 45
50
Response time
(EOS models)
ms 3,5 4,5 5,5 6,5 7,5 9 10 11 12 13
Response time
(Master + 1 slave)
ms
t
tot
= [0,11 * (Nr
slave1
+ Nr
master
) + 0,9376] * 2
Response time
(Master + 2 slaves)
ms
t
tot
= [0,11 * (Nr
slave1
+ Nr
slave2
+ Nr
master
) + 1,0508] * 2
Protected height
mm 160 310 460 610 760 910 1060 1210 1360 1510
Curtain tot. height mm
236.5 386.5 536.5 686.5 836.5 986.5 1136.5 1286.5 1436.5 1586.5
50 mm Resolution Models
155 305 455 605 755 905 1055 1205 1355 1505
Number of beams 4 8 12 16 20 24 28 32 36 40
Response time
(EOS models)
ms 3 4 4,5 5,5 6,5 7,5 8,5 9 10 11
Response time
(Master + 1 slave)
ms
t
tot
= [0,11 * (Nr
slave1
+ Nr
master
) + 0,9376] * 2
Response time
(Master + 2 slaves)
ms
t
tot
= [0,11 * (Nr
slave1
+ Nr
slave2
+ Nr
master
) + 1,0508] * 2
Protected height
mm 160 310 460 610 760 910 1060 1210 1360 1510
Curtain tot. height mm
236.5 386.5 536.5 686.5 836.5 986.5 1136.5 1286.5 1436.5 1586.5
90 mm Resolution Models 309 459 609 759 909 1059 1209 1359 1509
Number of beams 4 6 8 10 12 14 16 18 20
Response time
(EOS models)
ms
3 3,5 4 4,5 5 5,5 5,5 6 6,5
Response time
(Master +1 slave)
ms
t
tot
= [0,11 * (Nr
slave1
+ Nr
master
) + 0,9376] * 2
Response time
(Master + 2 slaves)
ms
t
tot
= [0,11 * (Nr
slave1
+ Nr
slave2
+ Nr
master
) + 1,0508] * 2
Protected height
mm
310 460 610 760 910 1060 1210 1360 1510
Curtain tot. height mm
386.5 536.5 686.5 836.5 986.5 1136.5 1286.5 1436.5 1586.5
Multibeam Models 2B 3B 4B
Number of beams 2 3 4
Distance between the beams mm 500 400 300
Response time ms 2,5 3 3
Curtain tot. height mm 677 977 1077

Reer EOS4 Specifications

General

Power Supply	24 VDC ±20%
Resolution	14 mm
Safety Category	Type 4
Operating Temperature	+55 °C
Protection Rating	IP65
Detection Capability	Opaque objects
Connection	M12 connector
Response Time	≤ 20 ms
Outputs	2 x safety outputs (OSSDs)
