Reer EOS4 User Manual

EOS4 SAFETY LIGHT CURTAIN
30 8540733 • 10th February 2009 • Rev.1
English
Accessories/Spares
MODEL ITEM CODE
AD SR1 ADMIRAL AD SR1 safety module 1330900
AD SRM ADMIRAL AD SRM safety module with muting function 1330904
AD SR0 ADMIRAL AD SR0 safety relay 1330902
AD SR0A ADMIRAL AD SR0A safety relay 1330903
CD5 Straight M12 5-pin female connector with 5-m cable 1330950
CD95 90° M12 5-pin female connector with 5-m cable 1330951
CD15 Straight M12 5-pin female connector with 15-m cable 1330952
CD915 90° M12 5-pin female connector with 15-m cable 1330953
CDM9 Straight M12 5-pin female connector PG9 1330954
CDM99 90° M12 5-pin female connector PG9 1330955
C8D5 Straight M12 8-pin female connector with 5m cable 1330980
C8D10 Straight M12 8-pin female connector with 10m cable 1330981
C8D15 Straight M12 8-pin female connector with 15m cable 1330982
C8D95 90° M12 8-pin female connector with 5m cable 1330983
C8D910 90° M12 8-pin female connector with 10m cable 1330984
C8D915 90° M12 8-pin female connector with 15m cable 1330985
C8DM9 Straight M12 8-pin female connector PG9 1330986
C8DM99 90° M12 8-pin female connector PG9 1330987
CDS03 0.3m cable with 2 straight M12 5-pin female connectors 1330990
CJBE3 3m cable with 2 straight M12 5-pin female connectors 1360960
CJBE5 5m cable with 2 straight M12 5-pin female connectors 1360961
CJBE10 10m cable with 2 straight M12 5-pin female connectors 1360962
TR30 Test rod diameter 30mm 1330962
TR40 Test rod diameter 40mm 1330963
TR50 Test rod diameter 50mm 1330964
SA 4
Set of 4 fastening accessories (brackets, inserts and bolts)
for models up to 1050
1310970
SA 6
Set of 6 fastening accessories(brackets, inserts and bolts)
for models from 1200
1310971
SAV4E Set of 4 vibration-damping supports (for models h=150) 1310972
SAV8E Set of 8 vibration-damping supports (for models h=300÷1050) 1310973
SAV12E Set of 12 vibration-damping supports (for models h=1200÷1500) 1310974

Reer EOS4 Specifications

General

Power Supply	24 VDC ±20%
Resolution	14 mm
Safety Category	Type 4
Operating Temperature	+55 °C
Protection Rating	IP65
Detection Capability	Opaque objects
Connection	M12 connector
Response Time	≤ 20 ms
Outputs	2 x safety outputs (OSSDs)
