Reflex Marine FROG-3 - 2 Specification Frog-3; Specification Summary

User Manual
FROG-3
Rev 19 Page12
2 SPECIFICATION FROG-3
2.1 Specification Summary
Model No.
FS-01 (320) Standard, FS-01 (340) Artic , FS-01 (370) Tropical
Payload
The Safe Working Load (SWL) of the Frog 3 is the total load of
passengers and luggage. SWL = 330 Kg(727 lbs).
The Allowable Passenger Load of the Frog 3 is the total
passenger load to be placed on the seats. APL = 270Kg (594
lbs)
Background: The safe working load (SWL) is relevant to the
selection of lifting apparatus and the approach to periodically
testing the unit to ensure integrity. The passenger load is
important, as this defines the ‘moving mass’ for which the
design of the Frog 3 suspension system is matched.
Frog 3 design assumes that 3 persons of 90Kg (198 lbs) are
loaded onto the seats, equivalent to 270 Kg of ‘moving mass’.
In addition to this, each passenger carries 20Kg (44lbs) of
luggage placed on the floor, 60 Kg of ‘static mass’. The
combined load is the SWL of 330 Kgs (727 lbs).
Or
1 person seated & 1 person in stretcher
Dimensions
Width 1
2200 mm
Width 2
2500 mm
Height
2900 mm
Weight
Max Gross Weight
815 kg (1796 lb)
Tare Weight
485 kg (1069 lb)
Manufacture
To ISO 9001:2008
Materials
Frame
SS 316 and A4 Stainless Steel
Central Column / Lift Eye
Grade 316 Stainless Steel
Lift Eye Connection Bolts
A4 Stainless Steel
Other Steel Components
SS 316 and A4 or A2 and Mild Steel Hot Dipped Galvanise
Buoyancy
Rotationally moulded MDPE shell with PU foam fill
Seats
GRP
Operating Temperatures
Standard Model FS-01 (320)
+50 deg C to -20 deg C
Arctic Model FS -01 (340)
+50 deg C to -40 deg C
Tropical Model FS-01 (370)
+50 deg C t0 +20 deg C
