11 APPENDIX C – PARTS AND MATERIAL SPECIFICATIONS
11.1 Parts
Due to the numerous revisions to the Frog 3 build over time and the variations between standard,
Arctic and Tropic version, we have decided to omit the most current parts listing from this User
Manual as it was a source of confusion for customers with older versions of Frog 3. Shortly Reflex
Marine will be offering a parts and kits lookup facility on the website where the customer can get a
direct listing of parts specific to each frog built. We believe this facility will aid the customer find the
correct parts. In the absence of having this facility up and running, please contact us directly on
support@reflexmarine.com if you require any assistance with identifying the correct replacement
parts for your FROG-3.
11.2 Definition According to Criticality
Critical components are those in which, if failure were to occur, there would be a high risk to the
safety of the passengers in the FROG-3. The critical components are all connected to the Main
Support Tube, which is the prime structural component in the design.
11.3 Fastener Specifications
Because of corrosion considerations, all fasteners on the FROG-3 are supplied in stainless steel
suitable for marine use. All nuts and bolts must be Grade A4 or A2. All nuts should be fitted with
NYLOC inserts where applicable.
11.4 Certification
Certification Supplied is identified with the following letters:
MC - Material Certificate
CC - Certificate of Conformance
LTC - Load test Certificate
NDE - Non-Destructive Examination Report
